Product Model
E2EY-X4C1
Selling Points
- 1Detects non-ferrous metals like aluminum with high accuracy.
- 2Features a sensing distance of 4mm ±10% for precise detection.
- 3Equipped with robust protection circuits including reverse polarity protection and surge suppressor.
- 4Operates within a wide voltage range of 12 to 24 VDC and consumes up to 20 mA.
- 5Offers IP67 rating for oil-resistant and vibration-resistant performance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Case material | Nickel-plated brass | Operation | NO/NC selectable |
Overall length (mm) | 60 | Shielded | Shielded |
Supply voltage | 12 to 24 VDC | Size | M18 |
Sensing Distance | 4 mm | Connection | PVC cable |
Output | NPN | Threaded length (mm) | 42 |
Mounting | Bracket with 18 mm mounting hole or M18x1 threaded hole. | Cable Length | 2 m |
Specifications may be subject to change without notice
