Product Model
E3Z-B86
Selling Points
- 1Retro-reflective Technology: Detects transparent objects up to 500 mm with high accuracy.
- 2Compact Design: Rectangular housing with a small footprint (10.8 mm x 31 mm x 20 mm).
- 3Durable Construction: Made from PBT material with IP67 protection against dust and water.
- 4Versatile Output: Supports both Light-ON and Dark-ON operation modes.
- 5Easy Installation: Equipped with an M8 4-pin connector for straightforward connection.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Body Type | Rectangular - Compact | Housing Material | Plastic |
Light Source | Red LED | Operation | L-ON/D-ON selectable |
Sensing Method | Retro-reflective | Supply Voltage | 12 to 24 VDC |
Output | PNP | Max Sensing Distance | 0.5 m |
Connection | M8 4-pin connector |
Specifications may be subject to change without notice
