Product Model
E6F-CWZ5G 100P\u002FR 2M
Selling Points
- 12m radial cable exit for flexible installation
- 2IP65 rated for dust and water resistance
- 312-24VDC power supply for versatile use
- 4100 pulses per rotation for precise measurement
- 5Maximum rotation speed of 5000 RPM
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Cable Length | 2 m | Cable exit | Radial |
Connection | Pre-wired | Function | Incremental |
IP rating | IP65 | Max. rotation speed | 5000 |
Output form | NPN/PNP | Power supply voltage | 12-24 VDC |
Shaft diameter | 10 | Size (diameter) | 60 |
Resolution (pulse/rotation) | 100 |
Specifications may be subject to change without notice
