Product Model
ZX-LD300
Selling Points
- 1High-speed response time of 150µs for fast and accurate measurements.
- 2Interchangeable sensor heads for greater flexibility in various applications.
- 3Small and light design for easy integration into complex systems.
- 4Modular platform concept for scalability and multipoint measurement capabilities.
- 5Advanced diffuse reflective sensing method with a resolution of 300 µm.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Analog Output | (-5 to +5V),(1 to 5V),(4 to 20 mA) | Cable length | 0.5 m |
Light source | Visible semiconductor laser 650nm | Supply voltage | 12 to 24 VDC |
Sensing method | Diffuse Reflective | Safety | Class II |
Resolution | 300 渭m | Height range | 300卤200 mm |
Beam Shape | Spot |
Specifications may be subject to change without notice
