Product Model
AS400
Selling Points
- 1Configure five output relay signals and one input signal for UPS shutdown or remote on/off.
- 2Bridge communication data between a computer and the UPS using SCI interface protocol.
- 3Ensure safe and efficient operation with dry contact normally opened or normally closed status.
- 4Simple installation process with clear instructions and minimal setup required.
- 5Compatible with various UPS systems, making it a versatile solution for different power needs.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Standards | IEC/EN EN60947-5-1 | Rated Operational Voltage | 230 ... 400 V AC |
Rated Current (In) | 6 A | Number of Contacts CO | 0 |
Number of Contacts NC | 0 | Number of Contacts NO | 0 |
Number of Switches | 0 | Mounting Type | Plug-In |
Environmental Information | 2CCY451206D0201 | Product Net Width | 9 mm |
Product Net Height | 91 mm | Product Net Depth / Length | 75 mm |
Product Net Weight | 45 g | Dimension Diagram | 9AKK107492A6192 |
ETIM 8 | EC000041 - Auxiliary contact block | ETIM 9 | EC000041 - Auxiliary contact block |
WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | WEEE B2C / B2B | Business To Business |
CN8 | 85365053 | eClass | V11.0 : 27371302 |
Object Classification Code | FC | Manufacturer ID | 2CCS500900R0151 |
Specifications may be subject to change without notice
