Product Model
BCM/S2.6.0.1
Selling Points
- 1Easily integrate Pt100 and Pt1000 temperature sensors with configurable analog inputs.
- 2Compact dimensions (34 mm x 135 mm x 74 mm) for seamless integration into various systems.
- 3Offers 15-bit resolution for precise temperature measurement.
- 4Simple clip connection for quick and secure installation.
- 5Ensured by ABB, a leading brand in industrial automation and control systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Degree of Protection | IP20 | Data Sheet, Technical Information | 9AKK107046A7503 |
Number of Inputs | Analog (0 ... 10 V / 4 ... 20 mA) 2 | Product Range | KNX |
Manual Operation | No | Number of Batteries | 0 |
Product Net Width | 34 mm | Product Net Height | 135 mm |
Product Net Depth / Length | 74 mm | Product Net Weight | 0.19 kg |
ETIM 9 | EC001420 - PLC analogue I/O-module | eClass | V11.0 : 27242201 |
UNSPSC | 32151705 | Object Classification Code | A |
WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | WEEE B2C / B2B | Business To Consumer |
Manufacturer ID | 2CDG120068R0011 |
Specifications may be subject to change without notice
