Product Model
BI-F-2.0.2
Selling Points
- 1Advanced PID Control for Precise Process Management
- 2Customizable Settings for Tailored Automation Solutions
- 3High Reliability and Durability in Industrial Environments
- 4User-Friendly Interface for Easy Operation and Maintenance
- 5Compatible with Various Industrial Control Systems
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Degree of Protection | IP20 | Data Sheet, Technical Information | 2CKA000073B5764 |
Sub-Function | LED controlling | Number of Inputs | 2 Analog (0 ... 10 V / 4 ... 20 mA) 2 |
Number of Input Channels | 2 | Number of Output Channels | 2 |
Compatible Bus Systems | free@home (TP) | Manual Operation | No |
Suitable for C-Load | No | Number of Batteries | 0 |
Product Net Width | 39 mm | Product Net Height | 12 mm |
Product Net Depth / Length | 40 mm | Product Net Weight | 0.043 kg |
Dimension Diagram | 9AKK108464A0432 | ETIM 9 | EC001584 - I/O device for bus system |
eClass | V11.0 : 27143145 | Object Classification Code | A |
WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | WEEE B2C / B2B | Business To Consumer |
Manufacturer ID | 2CDG510023R0011 |
Specifications may be subject to change without notice
