Product Model
BR-S 2/46/16H
Selling Points
- 1High-Pin Count: The BR-S 2/46/16H busbar offers 46 pins, ensuring multiple connections for enhanced electrical reliability.
- 2Robust Construction: Made from durable materials, this busbar is designed to withstand various environmental conditions.
- 3Compliance with EU Directives: Meets EU Directive 2011/65/EU and Amendment 2015/863, ensuring compliance with RoHS regulations.
- 4Versatile Applications: Suitable for industrial and commercial applications, including marine environments.
- 5Easy Installation: No additional installation documents required, making it a straightforward integration into your electrical setup.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Rated Operational Voltage | 400 V | Rated Conditional Short-Circuit Current (Inc) | 25 kA |
Rated Uninterrupted Current (Iu) | 80 A | Pitch | 17.8 |
Number of Poles | 2 | Number of Phases | 2 |
Connection Type | Pin | Number of Batteries | 0 |
Rated Cross-Section | 16 mm² | Width in Number of Modular Spacings | 46.0 |
Product Net Width | 0.03 mm | Product Net Height | 0.015 mm |
Product Net Depth / Length | 1016 mm | Product Net Weight | 0.241 kg |
ETIM 8 | EC000215 - Phase busbar | ETIM 9 | EC000215 - Phase busbar |
WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | WEEE B2C / B2B | Business To Business |
CN8 | 8538 90 99 | UNSPSC | 39121614 |
eClass | V11.0 : 27142207 | Manufacturer ID | 2CDL824001R1646 |
Specifications may be subject to change without notice
