Product Model
CP-PX 24/1.1
Selling Points
- 1High Power Contact Load Capability
- 2Sealed Protection for Reliability and Durability
- 3Compact Miniature Size for Space-Constrained Installations
- 4General Purpose Use with Versatility in Various Applications
- 5Manufactured by ABB, a Reputable Brand for Exceptional Performance and Quality
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product Net Width | 29 mm | Product Net Height | 51.5 mm |
Product Net Depth / Length | 78.5 mm | Product Net Weight | 0.17 kg |
Function | Switch mode power supply | Number of Phases | 1 |
Rated Input Voltage (UIN) | 100 ... 240 V AC | Input Voltage (Uin) | 90 ... 264 V AC |
Hold-up Time | (230 V AC) min. 20 ms | Rated Frequency (f) | 50 / 60 Hz |
Rated Frequency Limits | 47 ... 63 Hz | Characteristic of Output | Hiccup-mode |
Rated Output Power | 25 W | Output Power | 25 W |
Rated Output Voltage | 24 V DC | Rated Output Current | -20 °C ... +50 °C 1.1 A |
Output Current | 1.1 A | Output Current Maximum (Iout) | 1.1 A |
Rated Impulse Withstand Voltage (Uimp) | Input Circuit / Output Circuit 1.5 kV Input Circuit / PE 1.5 kV | Degree of Protection | Housing IP20 |
Pollution Degree | 2 | Connecting Capacity Input Circuit | Rigid 0.3 ... 2 mm² |
Connecting Capacity Output Circuit | Rigid 0.3 ... 2 mm² | Wire Stripping Length | Input Circuit 8 mm Output Circuit 8 mm |
Minimum Mounting Distance | Other Device Same Type, Horizontal 25 mm Other Device Same Type, Vertical 25 mm | Mounting on DIN Rail | No |
Standards | IEC/EN 63000 EN 55024 EN 55032 IEC 60950-1 | Tightening Torque UL/CSA | Input Circuit 0.5 in·lb Output Circuit 0.5 in·lb |
Ambient Air Temperature | Operation -20 ... +70 °C Storage -40 ... +85 °C | Object Classification Code | T |
ETIM 7 | EC002540 - DC-power supply | ETIM 8 | EC002540 - DC-power supply |
ETIM 9 | EC002540 - DC-power supply | eClass | V11.0 : 27040701 |
UNSPSC | 39121004 | Manufacturer ID | 1SVR427091R0000 |
Specifications may be subject to change without notice
