Product Model
CR-M3LSH
Selling Points
- 1Supports up to 30 A with 3PDT contacts for reliable switching.
- 2Available in various coil voltages (12-220 V DC / 12-230 V AC) to suit global applications.
- 3Simplifies circuit checks with a manual test button for quick and easy verification.
- 4Available for switch-sensitive signals, ensuring high precision and durability.
- 5Miniature design with screw terminals for easy installation in space-saving applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product Net Width | 16 mm | Product Net Height | 69 mm |
Product Net Depth / Length | 76 mm | Product Net Weight | 0.061 kg |
Function | Pluggable miniature interface relay CR-MX Accessory for interface relays CR-M | Sub-Function | Relay with built in LED Socket for miniature relays |
Sub-Function 2 | Logical socket for miniature relay 3 c/o | Rated Control Supply Voltage (Us) | 24 V AC |
Rated Operational Voltage | 250 V | Output Signal | 250 V / 7 A |
Terminal Type | Screw Terminals | Rated Operational Current AC-12 (Ie) | (230 V) 10 A |
Rated Insulation Voltage (Ui) | 2 V | Mounting Position | 1 |
Standards | CAN/CSA C22.2 No.14 IEC/EN 63000 IEC/EN 61984 UL 508 | Connecting Capacity Main Circuit UL/CSA | Flexible with Ferrule 2x 20-16 AWG Rigid 2x 20-14 AWG Stranded 2 x 20-14 AWG |
Flammability According to UL94 | V-0 | Ambient Air Temperature | Operation -40 ... +70 °C Storage -40 ... +70 °C |
Maximum Operating Altitude Permissible | 2000 m | Object Classification Code | K |
ETIM 7 | EC001456 - Relay socket | ETIM 8 | EC001456 - Relay socket |
ETIM 9 | EC001456 - Relay socket | eClass | V11.0 : 27371603 |
UNSPSC | 39122335 | Manufacturer ID | 1SVR405651R5100 |
Specifications may be subject to change without notice
