Product Model
CR-MX024AC2L
Selling Points
- 1Built with high-quality components for consistent performance.
- 2Pluggable miniature interface relay for easy integration into control systems.
- 3Operates at 24V AC with a contact rating of 7A and 250V.
- 4Includes a built-in LED for visual indication of relay status.
- 5Suitable for various industrial control applications due to its standard interface and high operational frequency.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product Net Width | 21.5 mm | Product Net Height | 35 mm |
Product Net Depth / Length | 28 mm | Product Net Weight | 0.037 kg |
Function | Pluggable miniature interface relay CR-MX | Sub-Function | Relay with built in LED |
Rated Control Supply Voltage (Us) | 24 V AC | Rated Operational Voltage | 250 V AC |
Rated Frequency (f) | 50 / 60 Hz | Output | 2 c/o (SPDT) contacts |
Output Signal | 250 V / 7 A | Terminal Type | Flat-Pin Connections |
Rated Operational Current AC-12 (Ie) | (230 V) 7 A | Rated Operational Current AC-15 (Ie) | (120 V) 2 A (230 V) 0.8 A |
Rated Operational Current DC-12 (Ie) | (24 V) 7 A | Rated Operational Current DC-13 (Ie) | (24 V) 1.9 A (120 V) 0.8 A |
Rated Impulse Withstand Voltage (Uimp) | Between Coil and Contacts 1.5 kV | Rated Insulation Voltage (Ui) | 250 V |
Degree of Protection | IP40 | Mounting Position | 1 |
Standards | CAN/CSA C22.2 No.14 IEC/EN 63000 IEC/EN 61810-1 UL 508 | Maximum Operating Voltage UL/CSA | 250 V AC |
Flammability According to UL94 | V-2 | Ambient Air Temperature | Operation -40 ... +70 °C Storage -40 ... +70 °C |
Maximum Operating Altitude Permissible | Without Derating 2000 m | Object Classification Code | K |
ETIM 7 | EC001437 - Switching relay | ETIM 8 | EC001437 - Switching relay |
ETIM 9 | EC001437 - Switching relay | eClass | V11.0 : 27371601 |
UNSPSC | 39122331 | Manufacturer ID | 1SVR405631R0100 |
Specifications may be subject to change without notice
