Product Model
CR-MX110DC4T
Selling Points
- 1Ideal for applications needing to isolate electrical signals.
- 21-year warranty and ISO9001 certification ensure high-quality performance.
- 3Available with or without an integrated test button for manual actuation.
- 4Pluggable function modules available for easy integration into various systems.
- 5Cadmium-free contact material for long-lasting performance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product Net Width | 21.5 mm | Product Net Height | 37 mm |
Product Net Depth / Length | 28 mm | Product Net Weight | 0.035 kg |
Function | Pluggable miniature interface relay CR-MX | Rated Control Supply Voltage (Us) | 110 V DC |
Rated Operational Voltage | 250 V AC | Output | 4 c/o (SPDT) contacts |
Output Signal | 250 V / 5 A | Terminal Type | Flat-Pin Connections |
Rated Operational Current AC-12 (Ie) | (230 V) 5 A | Rated Operational Current AC-15 (Ie) | (120 V) 1.9 A (230 V) 0.8 A |
Rated Operational Current DC-12 (Ie) | (24 V) 5 A | Rated Operational Current DC-13 (Ie) | (24 V) 1.8 A (120 V) 0.5 A |
Rated Impulse Withstand Voltage (Uimp) | Between Coil and Contacts 1.5 kV | Rated Insulation Voltage (Ui) | 250 V |
Degree of Protection | IP40 | Mounting Position | 1 |
Standards | CSA 22.2 No. 14 IEC/EN 63000 IEC/EN 61010-1 UL 508 | Maximum Operating Voltage UL/CSA | 250 V AC |
Flammability According to UL94 | V-2 | Ambient Air Temperature | Operation -40 ... +70 °C Storage -40 ... +70 °C |
Maximum Operating Altitude Permissible | Without Derating 2000 m | Object Classification Code | K |
ETIM 7 | EC001437 - Switching relay | ETIM 8 | EC001437 - Switching relay |
ETIM 9 | EC001437 - Switching relay | eClass | V11.0 : 27371601 |
UNSPSC | 39122331 | Manufacturer ID | 1SVR405643R8000 |
Specifications may be subject to change without notice
