Product Model
E233-24/60HZ
Selling Points
- 1Accurate Hour Tracking: Precise measurement of elapsed time with high reliability.
- 2Compact Design: Slim dimensions (17.5 mm width, 85 mm height, 58 mm depth) for easy installation.
- 3Robust Construction: Built to withstand industrial environments with a net weight of 0.055 kg.
- 4Easy Operation: Simple and intuitive interface for effortless operation.
- 5Compliance with EU Directives: Meets RoHS standards following EU Directive 2002/95/EC and amendments.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Rated Voltage (Ur) | 24 V AC | Rated Frequency (f) | 50 / 60 Hz |
Power Loss | 1.5 W | Accuracy | Reading Accuracy Class 0,01 h |
Environmental Information | 2CDU400019D0201 | Width in Number of Modular Spacings | 1.0 |
Product Net Width | 17.5 mm | Product Net Height | 85 mm |
Product Net Depth / Length | 58 mm | Product Net Weight | 0.05 kg |
ETIM 8 | EC001641 - Hour meter | ETIM 9 | EC001641 - Hour meter |
WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | WEEE B2C / B2B | Business To Consumer |
CN8 | 9029 10 00 | eClass | V11.0 : 27142313 |
Manufacturer ID | 2CDE400021R1601 |
Specifications may be subject to change without notice
