Product Model
MS2
Selling Points
- 1High sound level of 107 dB(A) for effective alerting.
- 2Low current consumption for energy efficiency.
- 332 customizable modes using DIP switches.
- 4Integrated diode for cable monitoring in ABB fire alarm control panels.
- 5Durable ABS (V0) housing with IP21C degree of protection.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Auxiliary Voltage AC/DC | 24 V DC | Power Loss | 1.232 W |
Number of Inputs | Analog (0 ... 10 V / 4 ... 20 mA) 1 | Mounting Type | Surface Mounted |
Manual Operation | No | Color | grey |
Number of Batteries | 0 | Degree of Protection | IP20 |
Product Net Width | 63 mm | Product Net Height | 63 mm |
Product Net Depth / Length | 63 mm | Product Net Weight | 0.2 kg |
ETIM 8 | EC000195 - Optical/acoustic signal device | ETIM 9 | EC000195 - Optical/acoustic signal device |
WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | WEEE B2C / B2B | Business To Consumer |
CN8 | 8531 10 30 | eClass | V11.0 : 27143234 |
Manufacturer ID | 2CDG220022R0011 |
Specifications may be subject to change without notice
