Product Model
OS125GB21LR-MNS
Selling Points
- 1Advanced Electrical Switching: The OS125GB21LR-MNS offers a 3-pole, front-operated design for precise control.
- 2Reliable Connection: Features left-in-right-out terminal connections for secure and efficient electrical connections.
- 3Integrated Auxiliary Contacts: Comes with 2pcs of OA1G10 auxiliary contacts factory mounted on top of the mechanism.
- 4Durable Construction: Built to withstand demanding electrical environments with robust materials.
- 5Global Availability: Available in multiple regions with local distributors for easy access and support.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product Net Weight | 2.1 kg | Fuse Size | A2 A3 A4 |
Fuse System | British Standard | Mounting Type | Base mounting |
Number of Poles | 3 | Operating Mode | Front Operated |
Rated Operational Voltage | Main Circuit 690 V AC | Standards | IEC 60947-3 |
Terminal Type | Lug terminals | Tightening Torque | 15 ... 22 N·m |
Tightening Torque | 15 ... 22 N·m | ETIM 8 | EC001040 - Fuse switch disconnector |
ETIM 9 | EC001040 - Fuse switch disconnector | UNSPSC | 39122233 |
IDEA Granular Category Code (IGCC) | 5291 >> Fuse switch disconnector | WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
Manufacturer ID | 1SCA147318R1001 |
Specifications may be subject to change without notice
