Product Model
OS125GD22LR-MNS
Selling Points
- 1MNS switchgear offers air circuit-breakers up to 6300A without derating, ensuring optimal electrical performance.
- 2The system is fully adaptable to customer needs with a wide range of configurations, including cables or bus ducts from top or bottom.
- 3Internal arc tested according to IEC 61641, ensuring the highest level of personnel safety during operation, inspection, and maintenance.
- 4Multilevel air circuit-breaker layout reduces the switchgear footprint, and withdrawable MCCBs and ACBs minimize repair time.
- 5Meets all market requirements with compliance to IEC 60439-1, IEC61439-1/-2, EN60439-1, and CEI 60439-1 standards.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product Net Weight | 2.6 kg | Fuse Size | NH000 NH00 |
Fuse System | DIN | Mounting Type | Base mounting |
Number of Poles | 4 | Operating Mode | Front Operated |
Rated Operational Voltage | Main Circuit 690 V AC | Standards | IEC 60947-3 |
Terminal Type | Lug terminals | Tightening Torque | 15 ... 22 N·m |
Tightening Torque | 15 ... 22 N·m | ETIM 8 | EC001040 - Fuse switch disconnector |
ETIM 9 | EC001040 - Fuse switch disconnector | UNSPSC | 39122233 |
IDEA Granular Category Code (IGCC) | 5291 >> Fuse switch disconnector | WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
Manufacturer ID | 1SCA129777R1001 |
Specifications may be subject to change without notice
