Product Model
OT160EFCC4A
Selling Points
- 1High amperage rating of 160A for heavy-duty applications.
- 24-pole configuration for versatile power distribution.
- 3IP20 enclosure for enhanced safety and protection.
- 4Non-fusible design for quick and easy operation.
- 5Compact dimensions (130 mm H x 150 mm W x 73 mm D) for space-efficient installation.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Degree of Protection | acc. to IEC 60529 IP65 | Pollution Degree | 3 |
Product Net Width | 280 mm | Product Net Height | 560 mm |
Product Net Depth / Length | 180 mm | Product Net Weight | 7.3 kg |
Cable Cross-Section | 120 mm² | Cable Entry Position | Up/Down |
Cable Outlets Per Side | II-flange / II-flange | Conventional Thermal Current (Ithe) | Fully Enclosed 160 A |
Degree of Protection | acc. to IEC 60529 IP65 | Enclosure Material | Plastic |
Handle Color | Red / Yellow | Handle Type | Pistol handle |
Maximum Mounted Auxiliary Contacts | 2 NO, 2 NC | Mounted Auxiliary Contacts | 1 NO, 1 NC |
Number of Poles | 4P | Pollution Degree | 3 |
Power Loss | at Rated Operating Conditions per Pole 6.5 W | Rated Insulation Voltage (Ui) | acc. to IEC/EN 60664-1 750 V |
Rated Operational Current AC-22A (Ie) | (380 ... 415 V) 160 A (500 V) 160 A (690 V) 160 A | Rated Operational Current AC-23A (Ie) | (380 ... 415 V) 135 A (500 V) 125 A (690 V) 80 A |
Rated Operational Power AC-23A (Pe) | (380 ... 415 V) 75 kW (500 V) 75 kW (690 V) 75 kW | Rated Operational Voltage | Main Circuit 750 V |
Object Classification Code | Q | WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
Manufacturer ID | 1SCA022745R6380 |
Specifications may be subject to change without notice
