Product Model
OT16ETMM3AE-L41
Selling Points
- 1Built to last with consistent performance.
- 2Rigid alu-zinc coated steel enclosure for durability.
- 3Hinged door with door lock for secure operation.
- 4Polyester powder coating for enhanced protection.
- 5Ideal for applications requiring high reliability and efficiency.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Degree of Protection | acc. to IEC 60529 IP65 | Pollution Degree | 3 |
Product Net Width | 150 mm | Product Net Height | 200 mm |
Product Net Depth / Length | 100 mm | Product Net Weight | 1.66 kg |
Cable Cross-Section | 0.75 ... 10 mm² | Cable Entry Position | Up/Down |
Cable Outlets Per Side | 2xø25.5+ø16.5 / 2xø25.5+ø16.5 | Connecting Capacity Main Circuit | Screw Clamp 0.75 ... 10 mm² Screw Clamp / PE Terminal 2pc,1.5 ... 25 mm² |
Conventional Thermal Current (Ithe) | Fully Enclosed 40 A | Degree of Protection | acc. to IEC 60529 IP65 |
Enclosure Material | Steel sheet | Enclosure Type | Ensto |
Handle Color | Red / Yellow | Handle Type | Selector handle |
Impact Resistance Rating | Housing IK09 | Maximum Mounted Auxiliary Contacts | 2 NO, 2 NC |
Mechanical Durability | 20000 | Mounted Auxiliary Contacts | 1 NO, 0 NC |
Neutral Type | No neutral terminal | Number of Auxiliary Contacts NC | 0 |
Number of Auxiliary Contacts NO | 1 | Number of Poles | 3P |
Pollution Degree | 3 | Position of Line Terminals | Top In - Bottom Out |
Power Loss | at Rated Operating Conditions per Pole 1.6 W | Rated Conditional Short-Circuit Current (Inc) | 6.5 kA |
Rated Insulation Voltage (Ui) | acc. to IEC/EN 60664-1 750 V | Rated Operational Current AC-22A (Ie) | (380 ... 415 V) 32 A (500 V) 32 A (690 V) 32 A |
Rated Operational Current AC-23A (Ie) | (380 ... 415 V) 16 A (500 V) 16 A (690 V) 10 A | Rated Operational Power AC-23A (Pe) | (380 ... 415 V) 7.5 kW (500 V) 7.5 kW (690 V) 7.5 kW |
Rated Operational Voltage | Main Circuit 750 V | Rated Short-Circuit Making Capacity (Icm) | (690 V) 0.705 kA |
Rated Short-time Withstand Current Low Voltage (Icw) | for 1 s 0.5 kA | Standards | IEC 60947-1, -3 |
Terminal Type | Screw Terminals | Tightening Torque | acc. IEC 60947-1 0.8 N·m |
Tightening Torque | acc. IEC 60947-1 0.8 N·m | Object Classification Code | Q |
ETIM 8 | EC000216 - Switch disconnector | WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
Manufacturer ID | 1SCA156593R1001 |
Specifications may be subject to change without notice
