Product Model
OTM800E4C21D380CN
Selling Points
- 1High-Voltage Capability: Operates at 3-phase voltages from 240 to 990 V, meeting IEC 60038 standards.
- 2Advanced Frequency Control: Offers static frequency deviation of ±2% and dynamic frequency range of ±5 Hz for both 50 Hz and 60 Hz.
- 3Enhanced Speed Feedback: Provides speed resolution with encoder at 0.005% of nominal speed and analog tach at 0.1% (16 bits).
- 4Robust Protection: Features UL Type Open protection class for converter modules and options.
- 5Versatile Environmental Adaptability: Operates in a wide range of temperatures (0 to +55°C) with derating options for different DC currents.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product Net Width | 610 mm | Product Net Height | 285 mm |
Product Net Depth / Length | 299 mm | Product Net Weight | 31.5 kg |
Ampere Rating | 800 A | ETIM 9 | EC000216 - Switch disconnector (low voltage) |
WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | Manufacturer ID | 2TFC800369R1001 |
Specifications may be subject to change without notice
