Product Model
OVR404 4L 40-440 P TS QS
Selling Points
- 1High Surge Protection: Offers a rated impulse current of 20 kA and a total discharge current of 160 kA.
- 2Compliant with Standards: Meets IEC/EN 61643-11 standards for surge protection.
- 3Compact Design: Suitable for DIN rail mounting, ensuring easy installation in modular systems.
- 4Wide Voltage Range: Compatible with 400/690 V AC nominal voltage systems.
- 5Integrated Auxiliary Contacts: Includes NO + NC contacts for enhanced functionality.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Rated Voltage (Ur) | 240 ⦠415 V AC | Voltage Protection Level ( Up) | 1.5 kV (L-N) 1.5 kV (N-PE) 1.5 kV |
Maximum Continuous Operating Voltage (Uc) | (L-PE) 275 V | Rated Service Short-Circuit Breaking Capacity (Ics) | 30 kA |
Discharge Current | Nominal (8 / 20 µs) 20 kA I (max, 8 / 20 µs) 20 kA | Power Loss | 1 W |
Number of Protected Poles | 4 | Transmission Standard | Mechanical |
Mounting Type | Plug-In | Number of Batteries | 0 |
Fuse Size | 1 modular spacing | Degree of Protection | IP20 |
Environmental Information | 9AKK108467A9561 | Product Net Width | 72 mm |
Product Net Height | 109 mm | Product Net Depth / Length | 90 mm |
Product Net Weight | 450 g | ETIM 8 | EC002495 - Measurement device for surge protection |
ETIM 9 | EC002495 - Measurement device for surge protection | WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
WEEE B2C / B2B | Business To Consumer | CN8 | 85369080 |
eClass | V11.0 : 27201114 | Object Classification Code | F |
Manufacturer ID | 2CCF606000A0003 |
Specifications may be subject to change without notice
