Product Model
OVR T2 2N 15-150 P U
Selling Points
- 1Protects against lightning and transient overvoltages, ensuring the longevity of sensitive equipment.
- 2Features a patented internal disconnection system that disconnects the internal circuit before components go into short-circuit, ensuring self-protection up to higher current values.
- 3Pluggable design facilitates maintenance by allowing worn cartridges to be replaced without isolating the electrical circuit.
- 4Handles high impulse current discharge currents, making it suitable for installations requiring robust surge protection.
- 5Includes a 3-year warranty for peace of mind, ensuring you're protected against defects and failures within the specified period.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Standards | UL 1449 Ed3 | Suitable For | To protect the systems against the transient overvoltage (lightning) |
Rated Voltage (Ur) | 150 V AC | Nominal AC Voltage of the System (Uo) | 120 V |
Voltage Protection Level ( Up) | 0.6 kV (L-N) 0.6 kV (N-PE) 0.6 kV | Maximum Continuous Operating Voltage (Uc) | (L-PE) 175 V |
Rated Service Short-Circuit Breaking Capacity (Ics) | 100 kA | Discharge Current | Nominal (8 / 20 µs) 5 kA I (max, 8 / 20 µs) 15 kA |
Short Circuit Withstand Icc | 100 kA | Arrester Class | II |
Number of Protected Poles | 3 | Number of Poles | 3 |
Number of Conductors | 3 | Transmission Standard | Optic |
Version | Plug-in | Mounting Type | DIN-Rail |
Preventive Maintenance Feature | No | Status Indicator | Yes |
Fuse Size | 3 modular spacing | Degree of Protection | IP20 |
Maximum Operating Altitude Permissible | Without Derating 5000 | Maximum Continuous Operating Voltage UL/CSA (MCOV) | (L-PE) 175 V (L-L) 303 V (L-N) 175 V (N-PE) 175 V |
Maximum Operating Voltage UL/CSA | 175 V | Short-Circuit Current Rating (SCCR) | 200 kA |
Type of Low Voltage Distribution System UL/CSA | Split Phase | Width in Number of Modular Spacings | 3 |
Product Net Width | 53.4 mm | Product Net Height | 90.5 mm |
Product Net Depth / Length | 64.8 mm | Product Net Weight | 0.36 kg |
ETIM 8 | EC000941 - Surge protection device for power supply systems | ETIM 9 | EC000941 - Surge protection device for power supply systems |
WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) | WEEE B2C / B2B | Business To Business |
CN8 | 85363090 | UNSPSC | 39121610 |
eClass | V11.0 : 27130805 | IDEA Granular Category Code (IGCC) | 4906 >> Surge suppressers |
Object Classification Code | 141DBC | Manufacturer ID | 2CTB802344R0000 |
Specifications may be subject to change without notice
