Product Model
C4020-8-W
Selling Points
- 1Advanced Filtration System: Equipped with a high-efficiency filter for precise air quality control.
- 2High Flow Rates: Supports maximum flow rates of up to 5,000 liters per minute.
- 3Robust Construction: Built with durable materials for long-lasting performance in harsh environments.
- 4Integrated Regulator: Includes a built-in regulator for precise pressure control.
- 5Versatile Port Options: Available in Rc1/8 to Rc1 port sizes for easy integration into various pneumatic systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Model no. | C4020 | Filter | F4000 |
Lubricator | R4000 | Port size | 8 : 1/4 |
Port thread type | Blank : Rc thread | Drainage | Blank :With manual drain cock |
Bowl material | Blank : Polycarbonate bowl | Element | Blank : 5μm |
Diff press detect | Blank : Without differential pressure detection port | Pressure range | Blank : 0.05 to 0.85 MPa |
Relief | Blank : With relief mechanism | Pressure gauge | Blank : Standard pressure gauge (G401-W) |
Flow direction | Blank : Standard flow (left to right) | Distributor | Blank : Without assembled component |
Pressure switch | Blank : Without pressure switch | Shut-off / lockout valve | Blank : Without valve |
Displayed unit | Blank : MPa display (Rc thread), psi display (NPT thread), bar display (G thread) | Piping adaptor set (included) | Blank : Not attached |
Adaptor thread type | Blank : None | Attachment gauge type | Blank : Not attached |
Specifications may be subject to change without notice
