Product Model
GWCR12-0
Selling Points
- 1Compact size for space-saving applications.
- 2Flame-resistant white body for safe use in various environments.
- 3Cross fitting design for easy connection and flexibility.
- 4Made from PBT resin for durability and resistance to chemicals.
- 5Quick and easy push-in connection for efficient piping setup.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Model no. | GWCR12-0 | Applicable tube O.D.∅ | 12mm |
L | 30.0mm | B | 23.0mm |
C | 20.0mm | E | 4.2mm |
F | 21.0mm | N | 12.0mm |
Min. bore size | 10mm | Effective sectional area | 35.9mm^2 |
Specifications may be subject to change without notice
