Product Model
GWL6-0
Selling Points
- 1Compact size for space-saving applications.
- 2Flame-resistant white body with UL94 V-0 standards.
- 3Easy push-in installation with V-shaped packing seal.
- 4Freely rotating elbow union for simplified piping work.
- 5No need for sealing tape, ensuring a secure and leak-free connection.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Model no. | GWL6-0 | Applicable tube O.D.∅ | 6mm |
L | 21.0mm | B | 17.5mm |
C | 12.5mm | N | 8.5mm |
E | 4.2mm | F | 13.5mm |
Min. bore size | 4.0mm | Effective sectional area | 7.5mm^2 |
Specifications may be subject to change without notice
