Product Model
GWMF48-0
Selling Points
- 1Compact design for space-saving applications.
- 2Flame-resistant white body for safe use in various environments.
- 3Twin run T, triple, male BSPT to metric tube configuration.
- 4Made from PBT resin for enhanced durability and flexibility.
- 5Easy to install with push-in fitting mechanism.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Model no. | GWMF48-0 | Applicable tube O.D.∅ A side | 4mm |
Applicable tube O.D.∅ B side | 8mm | L1 | 66.0mm |
L2 | 19.5mm | B1 | 16.0mm |
B2 | 19.5mm | C | 14.5mm |
F | 15.5mm | N1 | 11.5mm |
N2 | 39.0mm | P | 10.5mm |
Effective sectional area | 22.0mm^2 |
Specifications may be subject to change without notice
