Product Model
GWS10-0-X
Selling Points
- 1Compact design for space-saving applications.
- 2Metric tube compatibility for precise fits.
- 3PBT resin for durability and flame retardancy.
- 4Easy installation with push-to-connect mechanism.
- 5Suitable for clean room environments and pneumatic piping systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Model no. | GWS10-0-X | Applicable tube O.D.∅ | 10mm |
H | 23mm | L | 44.5mm |
B | 21.5mm | E | 1mm |
MxP | M20 x 1 | Installation hole diameter | 21mm |
Min. hole diameter | 8.0mm | Effective sectional area | 30mm^2 |
Specifications may be subject to change without notice
