Product Model
GWWY64-0
Selling Points
- 1Compact size for space-saving installations.
- 2Flame-resistant white body for safe work environments.
- 3Double Y (with R) fitting for versatile connections.
- 4Smooth insertion and secure sealing with V-shaped packing seal.
- 5Easy tubing removal with push ring mechanism.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Model no. | GWWY64-0 | Applicable tube O.D.∅ A side | 6mm |
Applicable tube O.D.∅ B side | 4mm | L | 39mm |
B1 | 17.5mm | B2 | 16.0mm |
C1 | 12.5mm | C2 | 10.0mm |
D | 21mm | E | 3.2mm |
F | 22mm | N | 15.5mm |
P | 11.0mm | Effective sectional area | 9.0mm^2 |
Specifications may be subject to change without notice
