Product Model
R3100-8-G4-T
Selling Points
- 1High precision actuation with ±1.0 mm stop accuracy.
- 2Robust design withstanding up to 100 °C ambient temperature.
- 3Customizable options including various bore sizes and stroke lengths.
- 4Double acting with solenoid valve for brake control.
- 5Oil-free operation for clean and reliable performance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Model no. | R3100 | Port size | 8 : 1/4 |
Port thread type | Blank : Rc thread | Pressure range | Blank : 0.05 to 0.85 MPa |
Relief | Blank : With relief mechanism | Pressure gauge | T : No pressure (gauge port(1/4) is assembled sealed) |
Flow direction | Blank : Standard flow (left → right), knob is on the bottom | Displayed unit | Blank : MPa display, Rc thread |
Pipe adaptor set (attachments) | Blank : Not attached | Adaptor thread type | Blank : None |
Attachment bracket type | Blank : Not attached | Attachment gauge type | Blank : Not attached |
Infotext | https://www.ckd.co.jp/kiki/en/product/detail/393/R%E2%80%BB%E2%80%BB00-G4?t=list&cid=69&sid=0 |
Specifications may be subject to change without notice
