Product Model
S1-B3-80

Selling Points
- 1Made from zinc alloy with satellite chrome plating for enhanced durability and resistance to corrosion.
- 2Compatible with SCA2, JSC3, and USC cylinders, offering a wide range of pneumatic system configurations.
- 3Push-to-connect fittings with male BSPT/metric threads for straightforward and secure mounting.
- 4Handles with load controllers ensure waterproof operation in various environments.
- 5Nickel-plated brass for a robust and long-lasting finish, ensuring reliable performance over time.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Parameter | Value | Parameter | Value |
---|---|---|---|
Model no. | S1-B3-80 | Applicable bore size | 80, 100mm |
C | 14mm | CD | 20mm |
CF | 65mm | CQ | 28mm |
D | 20mm | F | 12mm |
G | 10.0mm | K | 130mm |
KA | 93mm | KB | 30.0mm |
MR | 20mm | SD | 100mm |
SE | 60mm | WEIGHT | 1.64kg |
Specifications may be subject to change without notice
