Product Model
S1-P-40
Selling Points
- 1Engineered for precise operations with ±30 sec index accuracy and ±5 sec repeatability.
- 2Built with a strong output shaft moment of inertia, ensuring stable performance under various loads.
- 3Available in multiple sizes and configurations to suit diverse industrial needs.
- 4Withstand ambient temperatures from 0 to 45°C and humidity levels up to 85% RH.
- 5Meets ISO 4414 and JIS B 8370 standards, ensuring safety in critical applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Model no. | S1-P-40 | Applicable bore size | 40, 50mm |
A | 43.5mm | B | 36.2mm |
C | 1.15mm | D | 11.5mm |
CD | 12mm | Snap ring | Axis C type 12 |
WEIGHT | 0.04kg |
Specifications may be subject to change without notice
