Product Model

SRL3-100-Y

In Stock
Last updated: 2025/4/17
CKD Corporation SRL3-100-Y

Selling Points

  • 1Resistant to high loads and durable for long-lasting performance.
  • 2Available in a variety of bore sizes (φ12 to φ100) for diverse applications.
  • 3High-speed operation with a piston packing designed for efficiency.
  • 4Compatible with compressed air and features a common port or standard port option.
  • 5Optimized sealing enhances reliability and improves seal performance.
Product Details
SRL3-100-Y
CKD Corporation

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Model no.
SRL3-100-Y
Bore size
100mm
FA
220mm
FB
70mm
FC
120.5mm
FD
90mm
FE
60mm
FF
110mm
FG
140mm
FH
13mm
FI
14.0mm
FJ
10mm
FK
5mm
B
61.5mm
C
150mm

Specifications may be subject to change without notice
