Product Model
SU3035-A05-W
Selling Points
- 1The SU3035-A05-W ensures precise control of fluids in ultra-clean environments, ideal for semiconductor and liquid crystal industries.
- 2Equipped with cutting-edge pneumatic components, including pneumatic cylinders and electric actuators, for efficient fluid management.
- 3Designed to meet the stringent requirements of ultra-high level process control, ensuring high precision and performance in semiconductor-related equipment.
- 4Features super-effective automatic drive systems that enhance productivity by reducing manual labor at various stages of production.
- 5Built with Japanese-made key parts, guaranteeing high reliability and quality, with special magnetic materials for high corrosion resistance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Model no. | SU3035 | Outlet air atmospheric dew point | A : -20°C |
Inlet air pressure | 05 : 0.5 MPa | Option : Common exhaust | Blank : None |
Option : Reversed inlet and outlet | Blank : None | Infotext | https://www.ckd.co.jp/kiki/en/product/detail/84/SD%E3%83%BBSU%E3%83%BBSDM?t=list&cid=75&sid=0 |
A | 388mm | B | 393mm |
C | 508mm | D | 80mm |
E | 228mm | F | 55mm |
G | 97mm |
Specifications may be subject to change without notice
