Product Model
SU401E-05-W-C1
Selling Points
- 1Freon-free operation, preserving the ozone layer.
- 2Ultra-low dew point performance up to -60°C.
- 3Compact and space-saving design for easy installation.
- 4High efficiency with a purge ratio of 10% for reduced operation costs.
- 5Modular design for easy integration with peripheral devices.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Model no. | SU401E | Inlet air pressure | 05 : 0.5 MPa |
Unit type | C1 | Option : Common exhaust | Blank : None |
Option : Reversed inlet and outlet | Blank : None | Infotext | https://www.ckd.co.jp/kiki/en/product/detail/84/SD%E3%83%BBSU%E3%83%BBSDM?t=list&cid=75&sid=0 |
A | 160mm | B | 223mm |
C | 278mm | D | 80mm |
E | 55mm | F | 97.0mm |
G | 0.0mm |
Specifications may be subject to change without notice
