Product Model
UGPS3-1NR
Selling Points
- 1High precision 2-point output for precise contact and posture confirmation.
- 2Wide detection range of 0.02 to 0.15 mm and 0.03 to 0.4 mm.
- 3Digital display with threshold setting and output status indication.
- 4Blockage indicator lamp for quick detection of air flow path blockages.
- 5Easy operation with master gauge and real-time calibration capabilities.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Model No. | UGPS3 | Detection range scale | Blank : 0.03 to 0.4 |
Station No. | 1 : 1 station | Out type | N : NPN open collector (2 points) |
Regulator solenoid valve assembly position | R : Right side assembly (inlet port on right) | Port size | Blank : Rc1/4 |
Screen display | Blank: Displayed (factory default) | Connector cable | Blank : 5m connector cable is attached |
Pressure display unit | Blank : SI units only (domestic models) |
Specifications may be subject to change without notice
