Product Model
VCV-H10
Selling Points
- 1Designed for work under the microscope, ensuring high precision and accuracy.
- 2Ergonomically designed for comfort and ease of use, reducing operator fatigue.
- 3Leverages the power of existing CV soldering systems, enhancing operational efficiency.
- 4Built with rugged aluminum case for durability and long-lasting performance.
- 5Includes a hand pump, wedge spreader, and essential components for various soldering tasks.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Model No. | VCV | Performance | H : High vacuum type |
Nozzle diameter | 10 | Pressure switch | Blank : Without pressure switch |
A | 45mm | B | 33mm |
C | 16mm | D | 10mm |
E | 8mm | F | 14mm |
G | 20mm | H | 4.5mm |
2-ΦI(Mounting hole) | 4.5mm | J | Rp1/8 |
K | 10mm | L | Rp1/8 |
M | 30mm | N(Φ) | 15mm |
O | 14mm | P | 85mm |
Specifications may be subject to change without notice
