Product Model
VSKM-H05G-S416S1-1A-2
Selling Points
- 1Modular design with various units for customizable applications.
- 2Selectable nozzle diameters: 0.5, 0.7, 1.0, and 1.2 mm.
- 3Adjustable intake flow rate: 7 to 50 L/min (ANR).
- 4Built-in switching valve for quick air blow and fine adjustments.
- 5Compatible with solenoid valves and air timers for versatile control options.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Model no. | VSKM | Vacuum characteristics | H : High vacuum/medium flow rate |
Nozzle diameter | 05 : ø0.5 | Unit combination | G : Filter, Vacuum generating valve |
Vacuum port (V) | S4 : ø4 push-in fitting port position side | Air supply port (P) | 16 |
Exhaust port | S1 | Solenoid valve voltage | 1 : 100 VAC |
Valve type | A : Normaly open(NO) | Manifold station No. | 2 stations |
Vacuum switch specifications | Blank : No option |
Specifications may be subject to change without notice
