CKD CorporationFittings/tubes
Product Model

ZSP-M12

Manufacturer

CKD Corporation

Category

Fittings/tubes

Product ID

52142

In Stock
Last updated: 2025/4/21
View Specifications
CKD Corporation ZSP-M12

Selling Points

  • 1Durable Stainless Steel Construction: Made from SUS303 or equivalent stainless steel for high corrosion resistance.
  • 2Versatile Applications: Suitable for a wide range of pneumatic piping variations.
  • 3Environment-Friendly: Compliant with the RoHS Directive, ensuring no harmful substances affect the global environment.
  • 4Easy Installation: Push-in design for quick and hassle-free installation.
  • 5Wide Compatibility: Compatible with various tube O.D.s and port sizes (M5, 1/8, 1/4, 3/8, 1/2).
Product Details
ZSP-M12
CKD Corporation

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Model no.
ZSP-M12
Applicable tube outer diameter φ
12mm
M x P
M22 x 1
L1
47.6mm
L3
12.3mm
L2
29.0mm
C1
19.8mm
C2
20.4mm
B
23.3mm
H
27mm
T
6mm
Effective cross section area
71.0mm^2
Weight
81.0g

Specifications may be subject to change without notice
