CKD CorporationFittings/tubes
Product Model

ZSP-VX4-M5

Manufacturer

CKD Corporation

Category

Fittings/tubes

Product ID

52258

In Stock
Last updated: 2025/4/26
View Specifications
CKD Corporation ZSP-VX4-M5

Selling Points

  • 1High-functionality with improved environmental performance.
  • 2Enhanced safety and reliability through superior main valve sliding structure.
  • 3Long-lasting with low sliding friction and specially designed packing.
  • 4Easy manifold selection model available as a single unit.
  • 5Compatible with various industrial applications including assembly, handling, and inspection.
Product Details
ZSP-VX4-M5
CKD Corporation

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Model no.
ZSP-VX4-M5mm
Applicable tube outer diameter φ
4mm
Thread
M5x0.8mm
A
3.2mm
L1
21.7mm
G
23.5mm
C1
9.9mm
C2
10.0mm
B
14.9mm
L2
16.9mm
H
10.0mm
E
3.2mm
N
6.5mm
F
10.0mm
Effective cross section area
2.3mm^2
Weight
11g

Specifications may be subject to change without notice
