Product Model
ZW-S12-0
Selling Points
- 1Compact size saves space.
- 2Smooth insertion and secure sealing.
- 3Flame-resistant resin incorporated in white body and push ring (UL94 Standards V-0 equivalent).
- 4Stainless steel used for all metal parts.
- 5Compatible with various tube O.D. sizes (Φ4, Φ6, Φ8, Φ10, Φ12).
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Model no. | ZW-S12-0 | Applicable tube outer diameter φ | 12mm |
L | 47.5mm | B | 23.0mm |
C | 20.0mm | Min. bore size | 10.0mm |
Effective cross section area | 35mm^2 | Weight | 17.0g |
Specifications may be subject to change without notice
