Festo AEVC-63-10-A-P Short Stroke Cylinder - High Precision & Durability

Selling Points

1The AEVC-63-10-A-P features a precise piston diameter of 63 mm and a stroke length of 10 mm, ensuring accurate control in pneumatic systems.
2Equipped with elastic cushioning rings/pads at both ends, this cylinder provides smooth operation and reduces wear.
3With a corrosion resistance class of 1, the AEVC-63-10-A-P is suitable for applications requiring minimal corrosion impact.
4Compatible with operating pressures from 0.1 to 1 MPa and ambient temperatures from -20°C to +80°C, making it versatile for various industrial conditions.
5Made from high-quality materials including wrought aluminum alloy and high-alloy steel, ensuring durability and reliability in demanding environments.

Detailed engineering parameters based on manufacturer documentation

Parameter	Value	Parameter	Value
Stroke	10mm	Piston diameter	63 mm
Spring resetting force with piston rod in retracted position	50N	Based on norm	ISO 6431 Hole pattern VDMA 24562
Cushioning	Elastic cushioning rings/pads at both ends	Mounting position	Any
Mode of operation	Pushing Single-acting	Structural design	Piston Piston rod
Position sensing	None	Symbol	00991730
Operating pressure	14.5psi 145psi	Operating medium	Compressed air as per ISO 8573-1:2010 [7:4:4]
Information on operating and pilot media	Operation with oil lubrication possible (required for further use)	Corrosion resistance class (CRC)	1 - Low corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L	Ambient temperature	-20°C 80°C
Theoretical force at 6 bar, advancing	1799N	Moving mass	157g
Product weight	460g	Type of mounting	Optionally: With through-hole With accessories
Pneumatic connection	G1/8	Note on materials	RoHS-compliant
Cover material	Wrought aluminum alloy Anodized	Seals material	NBR TPE-U(PU)
Housing material	Wrought aluminum alloy Anodized	Piston rod material	High-alloy steel
Manufacturer ID	188282

Specifications may be subject to change without notice
