Product Model
cpe14-3/2-prs-3/8-4
Selling Points
- 1The CPE14-3/2-PRS-3/8-4 manifold block by Festo offers a compact design with a grid dimension of 20 mm, making it perfect for space-constrained industrial settings.
- 2This manifold block supports up to 4 valve positions and 2 pressure zones, providing flexible control over pneumatic systems in various industrial applications.
- 3With a burst pressure of 5 MPa (50 bar or 725 psi), the CPE14-3/2-PRS-3/8-4 manifold block ensures reliable operation under high-pressure conditions, making it suitable for demanding industrial processes.
- 4The manifold block features a moderate corrosion resistance class (CRC 2) and operates within a media temperature range of -5°C to 50°C, ensuring durability and performance in diverse environmental conditions.
- 5The CPE14-3/2-PRS-3/8-4 manifold block is designed with a through-hole mounting type and uses female threads for valve mounting, providing easy installation and integration into existing pneumatic systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width dimension | 20mm | Mounting position | Any |
Max. no. of valve positions | 4 | Max. no. of pressure zones | 2 |
Burst pressure | 725psi | Operating pressure | -0.9bar 10bar |
Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Temperature of medium | -5°C 50°C | Ambient temperature | -5°C 50°C |
Max. tightening torque for valve mounting | 1.2Nm | Product weight | 280g |
Manifold block type of mounting | With through-hole | Pneumatic valve mounting type | With internal thread |
Pneumatic connection 1 | G3/8 | Pneumatic connection 3 | G3/8 |
Pneumatic connection 5 | G3/8 | Note on materials | RoHS-compliant |
Manifold rail material | Wrought aluminum alloy | Manufacturer ID | 550561 |
Specifications may be subject to change without notice
