Product Model
cpe18-3/2-prs-3/8-5
Selling Points
- 1The CPE18-3/2-PRS-3/8-5 features a compact width of 26 mm, making it ideal for space-constrained applications in industrial automation.
- 2This solenoid valve is suitable for a variety of applications, including 3/2-way valves, and can be used in both internal and external pilot air supply configurations.
- 3With a maximum flow rate of up to 5 bar, the CPE18-3/2-PRS-3/8-5 ensures efficient operation in demanding industrial environments.
- 4The valve can be assembled in any position, offering flexibility in installation and integration into complex systems.
- 5Designed with a maximum number of valve positions and pressure zones, this valve ensures reliable operation and precise control in various industrial processes.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width dimension | 26mm | Mounting position | Any |
Max. no. of valve positions | 5 | Max. no. of pressure zones | 2 |
Burst pressure | 725psi | Operating pressure | -0.9bar 10bar |
Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Temperature of medium | -5°C 50°C | Ambient temperature | -5°C 50°C |
Max. tightening torque for valve mounting | 2Nm | Product weight | 507g |
Manifold block type of mounting | With through-hole | Pneumatic valve mounting type | With internal thread |
Pneumatic connection 1 | G3/8 | Pneumatic connection 3 | G3/8 |
Pneumatic connection 5 | G3/8 | Note on materials | RoHS-compliant |
Manifold rail material | Wrought aluminum alloy | Manufacturer ID | 550571 |
Specifications may be subject to change without notice
