Product Model
crqst-8
Selling Points
- 1The Festo CRQST-8 is a push-in T-connector designed for standard 5 mm nominal size connections, ensuring easy and secure assembly in any position.
- 2This high-alloy stainless steel fitting offers very high corrosion resistance (CRC 4) and is suitable for use with compressed air and water, making it ideal for diverse industrial applications.
- 3The CRQST-8 operates within a wide temperature range (-15°C to 120°C) and supports lubricated operation, enhancing its durability and performance.
- 4With two outputs and one supply line, this fitting is versatile and can be used in various configurations, including tube-to-tube connections.
- 5The CRQST-8 is RoHS-compliant and meets food safety standards, making it a reliable choice for applications requiring high hygiene levels.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Size | Standard | Nominal width | 5mm |
Mounting position | Any | Design | T-shape |
Pack size | 1 | Structural design | Push-pull principle |
Operating pressure for entire temperature range | -13.775psi 145psi | Information on operating pressure | Water: max. 0.6 MPa at max. 50 °C |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free) | Information on operating and pilot media | Operation with oil lubrication possible |
Corrosion resistance class (CRC) | 4 - Particularly high corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
For use in the food industry | See supplementary material information | Ambient temperature | -15°C 120°C |
Product weight | 37g | No. of outlets | 2 |
No. of supply lines | 1 | Usable connector cables | PFAN |
Pneumatic connection 1 | for pneumatic tubing outside diameter 8 mm | Pneumatic connection 2 | for pneumatic tubing outside diameter 8 mm |
Note on materials | RoHS-compliant | Housing material | High-alloy stainless steel |
Releasing ring material | High-alloy stainless steel | Material of tubing seal | FPM |
Material of tube retaining claw | High-alloy stainless steel | Thrust ring material | High-alloy stainless steel |
Manufacturer ID | 130670 |
Specifications may be subject to change without notice
