Product Model
dzf-2"- -a-p-a-s2
Selling Points
- 1The Festo DZF-2 1/2"-6"-A-P-A-S2 features a non-rotating oval piston, ensuring precise and reliable operation in various industrial settings.
- 2This pneumatic cylinder offers double-acting functionality, allowing for both extension and retraction strokes, making it versatile for a wide range of applications.
- 3The DZF-2 1/2"-6"-A-P-A-S2 includes flexible cushioning rings at both ends, reducing noise and vibration, and enhancing overall performance and longevity.
- 4With a maximum operating pressure of up to 10 bar, this cylinder is designed to handle medium to heavy loads, making it ideal for high-speed applications.
- 5The Festo DZF-2 1/2"-6"-A-P-A-S2 is equipped with a high-alloy steel piston rod, providing excellent running performance and a long service life.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Stroke | 1.016mm 330.2mm | Piston diameter | 2" |
Max. angle of rotation of the piston rod +/- | 0.5deg | Cushioning | Elastic cushioning rings/pads at both ends |
Mode of operation | Double-acting | Symbol | 00991219 |
Protection against torsion/guide | Oval piston | Operating pressure | 1bar 10bar |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] | Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Ambient temperature | -20°C 80°C | Theoretical force at 6 bar, retracting | 990N |
Theoretical force at 6 bar, advancing | 990N | Pneumatic connection | 1/4 NPT |
Cover material | Aluminum | Seals material | FPM TPE-U(PU) |
Housing material | Wrought aluminum alloy | Piston rod material | High-alloy steel |
Manufacturer ID | 194232 |
Specifications may be subject to change without notice
