Product Model
dzh-32- -ppv-a
Selling Points
- 1The DZH-32-PPV-A is a high-performance pneumatic valve designed to handle demanding industrial applications with precision and reliability.
- 2Equipped with advanced control mechanisms, this valve ensures precise flow regulation and optimal system performance.
- 3Built with durable materials, the DZH-32-PPV-A offers long-lasting operation and minimal maintenance requirements.
- 4Compatible with a wide range of Festo pneumatic systems, this valve integrates seamlessly into existing setups for enhanced efficiency.
- 5Ideal for use in various industries including manufacturing, automation, and robotics, the DZH-32-PPV-A delivers consistent performance in critical applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Stroke | 1mm 1000mm | Piston diameter | 32 mm Equivalent diameter |
Max. angle of rotation of the piston rod +/- | 1.7deg | Cushioning | Pneumatic cushioning, adjustable at both ends |
Mounting position | Any | Mode of operation | Double-acting |
Structural design | Piston Piston rod | Position sensing | For proximity sensor |
Symbol | 00991235 | Protection against torsion/guide | Oval piston |
Operating pressure | 0.6bar 10bar | Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
Information on operating and pilot media | Operation with oil lubrication possible (required for further use) | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
LABS (PWIS) conformity | VDMA24364-B2-L | Ambient temperature | -20°C 80°C |
Cushioning length | 19mm | Max. torque for protection against rotation | 1Nm |
Theoretical force at 6 bar, retracting | 415N | Theoretical force at 6 bar, advancing | 483N |
Additional weight per 10?mm stroke | 30g | Basic weight with 0?mm stroke | 500g |
Type of mounting | Optionally: With internal thread With accessories | Pneumatic connection | G1/8 |
Note on materials | RoHS-compliant | Cover material | Aluminum |
Seals material | TPE-U(PU) | Housing material | Aluminum |
Piston rod material | High-alloy steel | Manufacturer ID | 14040 |
Specifications may be subject to change without notice
