Product Model
esg-20
Selling Points
- 1Anti-static design for sensitive environments
- 2Durable materials (BR, FPM, NBR, PUR, VMQ)
- 3Vertical mounting position for versatile use
- 4Vacuum connection at top with height compensation
- 5Operating temperature range: -30 °C to 200 °C
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Suction cup diameter | 20mm | Mounting position | Vertical |
Special features | Anti-static | Structural design | Vacuum connection at top Vacuum connection at side with height compensation with long height compensation |
Classification of suction cup holder | Size 4 | Suction cup shape | Round bellows, 1.5 convolutions Round bellows, 3.5 convolutions Round, extra-deep Round, flat |
Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] | Corrosion resistance class (CRC) | 1 - Low corrosion stress |
Ambient temperature | -30°C 200°C | Vacuum connection | M14x1 G1/8 QS-6 PK-4 |
Note on materials | RoHS-compliant | Suction cup material | BR FPM NBR PUR VMQ (silicone) |
Manufacturer ID | 189173 |
Specifications may be subject to change without notice
