Product Model
esh-ha-3-qs
Selling Points
- 1Top vacuum connection for seamless integration.
- 2Made with POM high-alloyed steel and quenched tempered steel for durability.
- 3Corrosion-resistant class KBK 1 ensures long-lasting performance.
- 4Secured by locking nut with M4 suction cup mounting.
- 5RoHS compliant and NBR seals for environmental safety.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Nominal width | 5mm | Volume | 0.52cm3 |
Mounting position | Any | Structural design | Vacuum connection at top |
Classification of suction cup holder | Size 3 | Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] |
Corrosion resistance class (CRC) | 1 - Low corrosion stress | LABS (PWIS) conformity | VDMA24364-A1-L |
Ambient temperature | 0°C 60°C | Product weight | 20g |
Type of mounting | With lock nut | Suction cup mounting | M4 |
Vacuum connection | QS-6 | Note on materials | RoHS-compliant |
Seals material | NBR | Retaining bracket material | Aluminum Brass, nickel-plated POM Tempered steel High-alloy steel |
Manufacturer ID | 189197 |
Specifications may be subject to change without notice
