Product Model
esv-100-eu

Selling Points
- 1The Festo ESV-100-EU pneumatic cylinder is engineered for high efficiency, ensuring optimal performance in a wide range of industrial applications. Its streamlined design reduces energy consumption and enhances overall productivity.
- 2Built with robust materials and precision engineering, the ESV-100-EU offers reliable operation even in demanding environments. Its durable construction ensures minimal downtime and maximum uptime, making it an ideal choice for critical applications.
- 3The ESV-100-EU is designed to meet the needs of various industries, including manufacturing, logistics, and automation. Its versatility allows it to be easily integrated into different systems, making it a one-stop solution for many applications.
- 4Festo's commitment to simplicity is evident in the ESV-100-EU's design. The cylinder features easy-to-use maintenance parts, reducing the time and effort required for upkeep. This ensures that your operations run smoothly with minimal interruptions.
- 5As part of Festo's extensive global network, the ESV-100-EU is available worldwide. This means you can access the product quickly and easily, regardless of your location. With fast shipping and reliable logistics, you can get the components you need when you need them.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Parameter | Value | Parameter | Value |
---|---|---|---|
Min. workpiece radius | 200mm | Suction cup diameter | 100mm |
Suction cup volume | 79.812cm3 | Connection position | Top |
Mounting position | Any | Symbol | 00991485 |
Suction cup shape | Round, extra-deep | Operating pressure | -13.775psi 0psi |
Nominal operating pressure | -10.15psi | Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] |
LABS (PWIS) conformity | VDMA24364 zone III | For use in the food industry | See supplementary material information |
Ambient temperature | -20°C 60°C | Holding force at nominal operating pressure | 440.8N |
Product weight | 65g | Color | Blue |
Shore hardness | 60 +/- 5 | Note on materials | RoHS-compliant |
Suction cup material | PUR | Manufacturer ID | 191048 |
Specifications may be subject to change without notice
