Product Model
grf-pk-3x2
Selling Points
- 1Precise Flow Control - The Festo GRF-PK-3X2 offers precise control over pneumatic flow with its knurled screw adjustment, ensuring reliable operation in various industrial settings.
- 2Wide Operating Pressure Range - This valve operates effectively between 0.5 to 8 bar, making it versatile for different pneumatic systems and applications.
- 3Durable Construction - Made from aluminum wrought alloy, the GRF-PK-3X2 provides a durable and long-lasting solution for your pneumatic needs.
- 4Easy Installation - With throughway bores for fastening and arbitrary installation positions, the GRF-PK-3X2 is easy to integrate into your existing setup.
- 5Compliant with ISO Standards - Designed to operate with compressed air to ISO 8573-1:2010, this valve ensures compliance with industry standards for quality and performance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Valve function | Flow control non-return function | Pneumatic connection 1 | PK-3 |
Pneumatic connection 2 | PK-3 | Adjusting element | Knurled screw |
Type of mounting | With through-hole | Standard nominal flow rate in flow control direction | 45l/min |
Standard nominal flow rate in non-return direction | 45l/min | Operating pressure | 0.5bar 8bar |
Ambient temperature | -10°C 60°C | Housing material | Wrought aluminum alloy |
Mounting position | Any | Symbol | 00991453 |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] | Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
LABS (PWIS) conformity | VDMA24364-B1/B2-L | Temperature of medium | -10°C 60°C |
Product weight | 145g | Material of adjusting screw | Brass |
Manufacturer ID | 4566 |
Specifications may be subject to change without notice
