Product Model
grlsa-1/8-qs-6
Selling Points
- 1The GRLSA-1/8-QS-6 one-way flow control valve is designed to ensure reliable and efficient pneumatic automation systems, providing a consistent flow of compressed air.
- 2This valve features a rod eye, proximity sensor, blanking plug, and rod clevis, making it versatile for various applications in factory automation.
- 3With a focus on quality and reliability, the GRLSA-1/8-QS-6 is built to withstand maximum vibration and shock loads, ensuring long-term performance.
- 4The valve is compliant with ambient temperature and medium temperature specifications, ensuring optimal operation in a wide range of environments.
- 5The GRLSA-1/8-QS-6 has a service-life value of 10 million cycles, making it a durable choice for demanding industrial applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Valve function | Exhaust air flow control non-return function | Pneumatic connection 1 | QS-6 |
Pneumatic connection 2 | G1/8 | Actuation type | Manual |
Adjusting element | Internal hexagon | Type of mounting | Screw-in |
Standard nominal flow rate in flow control direction | 0l/min 250l/min | Standard nominal flow rate in non-return direction | 180l/min 310l/min |
Ambient temperature | -10°C 60°C | Mounting position | Any |
Symbol | 00991475 | Operating pressure for entire temperature range | 0.2bar 10bar |
Standard flow rate in flow control direction 6 -> 0 bar | 0l/min 410l/min | Standard flow rate in non-return direction at 6 -> 0 bar | 430l/min 540l/min |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] | Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
LABS (PWIS) conformity | VDMA24364-B2-L | Cleanroom class | Class 4 according to ISO 14644-1 |
Storage temperature | -10°C 40°C | Temperature of medium | -10°C 60°C |
Nominal tightening torque | 3.5Nm | Tolerance for nominal tightening torque | ± 20% |
Product weight | 19.5g | Seals material | NBR |
Hollow bolt material | Wrought aluminum alloy Anodized | Releasing ring material | POM |
Material of adjusting screw | PA-reinforced | Swivel joint material | Die-cast zinc |
Manufacturer ID | 540661 |
Specifications may be subject to change without notice
